The filling station is used as a device for filling gas bottles. It is installed on the explosion-proof wall or wall of the filling room with a fixed bracket. It consists of two left and right manifolds. There are two high-pressure valves connected in the middle. The entire filling station is divided into two groups. Each group is composed of several valves and a return valve or a vent valve. One group of cylinders can be filled at a time, so that the two rows can take turns. Work. A pressure gauge and safety valve are installed in the middle to ensure safety and feasibility.
Technical Parameters
· Applicable media: Oxygen
· Working pressure: 15MPA
· Materials : stainless steel, copper tube
Model | No. of Filling Outlets |
GC-2*2 | 4 |
GC-3*2 | 6 |
GC-4*2 | 8 |
GC-5*2 | 10 |
GC-6*2 | 12 |
GC-8*2 | 16 |
GC-10*2 | 20 |
For more models please our sales team.
We can provide stand-along, wall-mounted types filling stations.The cylinder filling manifold stand height can be designed to be compatible with different standard cylinders, for example the 240 CFT bull nose type standard cylinders
Each Project is Custom-Built!
SPEAK WITH AN EXPERTAt CAN GAS, we listen to your demands and design the best possible solution for you. You can get the full line from air compressor to high quality cylinders – whatever your need may be.
We design your specific solution based on application, capacity, purity, pressure, classification requirements, ambient conditions, and height above sea level.
